Genius 5000 XRF Xray Fluorescence Analyzer

Price:

$9,818.00

SKU:

TSS00979

Brand:

Genius

Condition:

Used

Rating:

Availability:

In Stock

Shipping:

$120.00 (Fixed shipping cost)

Genius 5000 XRF X-ray Fluorescence Analyzer Handheld Ruggedized Spectrometer

Technical Specifications:

Detector: Si-PIN detector
Excitation source: mini 40kV/50µA X-ray tube, Ag anode end window.
Detection time: 10-200 S (handheld or stand).
Forms: Solid, liquid, powder.
Choose up to 26 elements to be tested simultaneously.
Detection limit: 10ppm Empirical, 0.01% or 100 ppm FP.
Calibration for FP method using pure Ag sample supplied.
Safety: Administrator model with password protection, no operators can use it without authorization.
Data usage: Edited inside PDA, and stored in PC for saving and printing.
16gb storage card included.
Power: Batteries will operate unit for more than 4 hours per charge.
Weight: 1.35kg
Ambient operating temperature: -20 deg to 120 deg F.
Standard Configuration:
PDA/Si-PIN detector / amplifier circuit / x-ray tube and high and low voltage power.
Weather proof case.
Mineral sample analysis, alloy, elemental FP methods installed in software.
Comes with SD memory card, SD card reader.
Optional items are, lab test stand, solar or car charger.

In good working and cosmetic condition. Tested and works.

We will ship within one business day. International consumers are welcome

Feel free to ask any questions. We constantly joyful to help you.
